NVR-8300WAP

Hi, how can I help you?Chat Now!

  • Model Number：   NVR-8300WAP
  • Rated Power：   200W
  • Application：  PC computer, NVR/DVR, machine
  • Fan Type：  8cm
  • Power Type：  NVR/DVR power supply
  • Input Voltage：  100-240VAC
  • High efficiency：  85%
  • Dimention：  125x100x63.5mm
  • Packaging Details：  10pcs/ctn
  • Carton Dimention：  420x370x145mm

10 Other Products in the same category

Product Features

• In accordance with SFX12V version 3.2
• Support Dual Core CPU Technology
• Active PFC
• The input voltage of AC 100-240V
• High efficiency
• Low output ripple noise
• Each output with over voltage protection
• Each output voltage with short-circuit protection
• 6CM cooling fan
• The built-in fan speed control, low noise
• 100% high temperature aging test (50℃)
• Life cycle: more than 100KH hours

Product Details

Connector
    • Motherboard cable (20+4-Pin) x 1
    • CPU power Cable (works as either 4 or 8-Pin) x 1
    • 4-Pin peripheral cable x 2
    • SATA cable x 2

    • Motherboard Cable

      20+4-Pin*1

    • CPU power Cable

      4-Pin*1

    • HDD power Cable

      SATA*2

    • HDD power Cable

      4-Pin*2

Parameters
  • AC Input: 100-240Vac，3A，47-63Hz
    DC Output:
    • +3.3V(Orange):
    • 12A
    • +5V(Red):
    • 12A
    • +12V1(Yellow):
    • 14A
    • -12V(Blue):
    • 0.5A
    • +5VSB(Purple):
    • 2.0A
    • -5V(White):
    • -A
    Output power: Max Power：300W，Rated Power：200W
Parameters
    • PFC: Active
    • Protection function： OVP， OPP， SCP
    • Cooling system: SPEED: 3500RMP(+/-10%)
      TEMP.AUTO ONTROL:1800rpm at 41.7℃~3500rpm at 60.5℃
      8CM Fan
    • Noise: 22dB at 3200rpm
    • P.G signal: 100-500ms
    • Keep time: 17ms(min)
    • Conversion efficiency：75%
    • MTBF：100000 hours
    • Working temperature：0-50℃
Accessories
    • Packing list：
      Power Supply x1
      Power line x1

Dimensions
  • NVR-8300WAP
