RYT-400U

Hi, how can I help you?Chat Now!

  • Model Number：   RYT-400U
  • Rated Power：   300W
  • Application：  The gateway computer industry, network, server, firewall
  • Fan Type：  4cm*2
  • Power Type：  Desktop / industrial computer
  • Input Voltage：  115VAC/220VAC
  • High efficiency：  85%
  • Dimention：  200x100x40mm
  • Packaging Details：  10pcs/ctn
  • Carton Dimention：  580x295x185mm

10 Other Products in the same category

Product Features

• In accordance with 1U version 2.01
• Support Dual Core CPU Technology
• High efficiency
• Low output ripple noise
• Each output with over voltage protection
• Each output voltage with short-circuit protection
• 2 built-in 4CM cooling fan
• 100% high temperature aging test (50℃)
• Life cycle: more than 100KH hours
• Suitable for: IDC, server, game machine, computer, industrial computer etc.

Product Details

Connector
    • Motherboard cable (20+4-Pin) x 1
    • CPU power Cable (4+4-Pin) x 1
    • 4-Pin peripheral cable x 2
    • SATA cable x 3
    • Floppy power adapter cable x 1

    • Motherboard Cable

      20+4-Pin*1

    • CPU power Cable

      4+4-Pin*1

    • HDD power Cable

      SATA*3

    • HDD power Cable

      4-Pin*2\4-Pin*1

Parameters
  • AC Input: 115/230Vac，3A，47-63Hz
    DC Output:
    • +3.3V(Orange):
    • 20A
    • +5V(Red):
    • 30A
    • +12V1(Yellow):
    • 20A
    • -12V(Blue):
    • 0.5A
    • +5VSB(Purple):
    • 2.0A
    • -5V(White):
    • -A
    Output power: Max Power：400W，Rated Power：300W
Parameters
    • PFC: Passive
    • Protection function： OVP， OPP， SCP
    • Cooling system: SPEED: 9000RMP(+/-10%)
      4CM Fan*2
    • Noise: 25dB at 9000rpm
    • P.G signal: 100-500ms
    • Keep time: 17ms(min)
    • Conversion efficiency：75%
    • MTBF：100000 hours
    • Working temperature：0-50℃
Accessories
    • Packing list：
      Power Supply x1
      Power line x1
